Massive storage capacity with 4K Ultra HD capability
Synology DS418play is designed to be your ideal, centralized multimedia hub with over 40TB of raw storage capacity, allowing you to transcode up to 2 channels of H.265/H.264 4K videos at the same time. With a powerful built-in AES-NI hardware encryption engine, DS418play also provides excellent encrypted file transmission.
4K Multimedia Server
Access and stream your 4K media content anytime and anywhere. DS418play supports 4K H.264/H.265 online transcoding via Video Station and DS video, allowing 4K videos to be converted and played on the fly on other computers, smartphones, and media players that originally do not support Ultra HD formats.
Next-generation file system for better data protection
The Btrfs file system introduces advanced storage technologies and optimized snapshots to prevent data corruption and reduce maintenance overhead. While ensuring high-level data integrity, it also offers flexible, efficient data protection and recovery tools.
Synology Hybrid RAID (SHR) technology
Storage management is easy with Synology Hybrid RAID (SHR) technology. SHR is an automated RAID management system allowing you to easily create and expand storage volumes and migrate RAID types without requiring details on RAID. SHR provides 1 to 2-disk redundancy to safeguard your data during drive failures.
Easy file access with QuickConnect
Access files on your Synology NAS over the Internet without the hassle of setting up port forwarding rules, DDNS, or other complicated network settings. QuickConnect allows you to connect via a simple customizable address (e.g. customID.quickconnect.to), so that you can instantly access media and work files on any Windows/Mac/Linux computer, laptop, or mobile device without additional charge.
Specificaties
Processor
Frequentie van processor
2,00 GHz
Processorfamilie
Intel? Celeron?
Processormodel
J3355
Aantal processorkernen
2
CPU configuratie (max)
1
ECC ondersteund door processor
PCI Express configuraties
1x2+2x1,4x1
PCI Express slots versie
2.0
Maximale turbofrequentie van processor
2,50 GHz
Processor cache
2 MB
Processor cache type
Smart Cache
Processorcode
SR2Z8
Codenaam processor
Apollo Lake
Processor lithografie
14 nm
Processor operating modes
64-bit
Verpakkingsgrootte processor
24 x 31 mm
Processor socket
BGA 1296
Processor aantal threads
2
Stepping
B1
Systeembus
5 GT/s
Tjunction
105 ?C
Thermal Design Power (TDP)
10 W
Maximaal intern geheugen ondersteund door processor
8 GB
Conflictvrije processor
ARK ID processor
95597
Geheugen
Intern geheugen
2 GB
Intern geheugentype
DDR3L
Poorten & interfaces
Aantal Ethernet LAN (RJ-45)-poorten
2
USB-poort
Aantal poorten USB 3.0 (3.1 Gen 1) Type A
2
Gewicht en omvang
Breedte
199 mm
Diepte
223 mm
Hoogte
166 mm
Gewicht
2,23 kg
Energie
Capaciteit voedingsunit (PSU)
90 W
Typisch stroomverbruik
29,01 W
Slaapstand
5,57 W
AC invoer voltage
100-240 V
AC invoer frequentie
50 - 60 Hz
Eisen aan de omgeving
Temperatuur, in bedrijf
5 - 40 ?C
Relatieve luchtvochtigheid, in bedrijf
5 - 95 procent
Temperatuur bij opslag
-20 - 60 ?C
Netwerk
Ethernet LAN
Wi-Fi
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s
iSCSI support
Wake-on-LAN
Opslagmedia
Opslagdrives ge?nstalleerd
Ge?nstalleerde opslag-drive
Ondersteunde types opslag-drives
HDD,SSD
Aantal storage drives ondersteund
4
RAID support
Hot-swap drive bays
Ondersteunde opslagstationinterfaces
SATA, SATA II, SATA III
Opslagschijf afmetingen ondersteund
2.5,3.5"
Soorten RAID
0,1,5,6,10,JBOD
Ondersteunde bestandsystemen
FAT,HFS+,NTFS,ext3,ext4
Certificaten
RoHS compliance
Inhoud van de verpakking
Externe adapter
Meegeleverde kabels
AC,LAN (RJ-45)
Snelle installatiehandleiding
Design
Type behuizing
Desktop
Type koeling
Actief
Kleur van het product
Zwart
Aantal ventilatoren
2 ventilator(en)
Grafisch
On-board graphics adapter model
Intel? HD Graphics 500
Basisfrequentie ingebouwde grafische adapter
250 MHz
On-board grafische adapter burst frequentie
700 MHz
Maximaal geheugen ingebouwde grafische adapter
8 GB
Aantal displays ondersteund (door on-board grafische adapter)
3
Processor speciale functies
Ingebouwde opties beschikbaar
Enhanced Intel SpeedStep Technology
Execute Disable Bit
Idle States
Intel? 64
Intel? Clear Video-technologie
Intel? Enhanced Halt State
Intel? Rapid Storage Technology
Intel? Veilig opstarten
Intel? Smart Connect Technology
Intel? Stable Image Platform Program (SIPP)
Intel? Trusted Execution Technology
Intel? Virtualization Technology (VT-x)
Intel? Virtualization Technology for Directed I/O (VT-d)
Intel? VT-x with Extended Page Tables (EPT)
Intel? AES New Instructions (Intel? AES-NI)
Intel? Anti-Theft Technology (Intel? AT)
Intel? Clear Video HD Technology (Intel? CVT HD)
Intel? Clear Video Technology for Mobile Internet Devices (Intel? CVT for MID)
